EWP 6m 19ft with 230kg capacity mini scissor lift for maintanence

Name: EWP 6m 19ft with 230kg capacity mini scissor lift for maintanence
Brand: JESH
Price: 1 USD

Buy cheap EWP 6m 19ft with 230kg capacity mini scissor lift for maintanence product

Brand Name : JESH

Model Number : SS0607HM

Certification : CE

Place of Origin : China

MOQ : 1Unit

Price : Negotiation

Payment Terms : T/T, L/C, D/P, D/A

Supply Ability : 4000 Units per month

Delivery Time : 45 days

Packaging Details : Regular factory packing

Color : Green

Working Height : 7.9m

Platform Height : 5.9m

width : 0.74m

Length : 1.84m

Capacity : 230KG

Weight : 1500kg

Overall Dimensions : 1.84x0.76x2.18m

Platform Size : 1.66x0.75x1.24m

Engine : Koher

Contact Now

Technical Parameters

Model	SS0607HM
Dimentions
Working height	7.9m
Platform height	5.9m
Max drive height	5.9m
Platform length	1.63m
Platform length-extended	2.53m
Platform extendable	0.9m
Platform width	0.74m
Height-rails unfolded	2.20m
Height-rails folded	1.79m
Width	0.76m
Length	1.84m
Wheelbase	1.32m
Ground clearance-stowed	7cm
Ground clearance-raised	2cm
Productivity
Platform capacity	230kg
Capacity on extension	100kg
Drive speed	3.2km/h
Gradeability	25%
Raise/lower speed	16/26sec
Turning radius(inside/outside)	0/1.5m
Tire	32.3x 10cm
Power
Battery	24V/225Ah
Hydraulic oil tank capacity	10L
Weight	1500kg

EWP 6m 19ft with 230kg capacity mini scissor lift for maintanence

Product Description

Small 6m elevated work platform is widely used in indoor workshop building site, hotel, airport, station, dock and so on.Mainly used to installing, repairing and cleaning on high aerial works.

Packaging & Shipping

Jesh Standard packing,with hard plastic bag to cover the whole machine and with steel wire holds the machine foot.

Shipping by sea with around 40-45 days arrrive your destination port.

Our Services

We provide long term warranty: 5 years for the main structural,2 years for the whole machine.

If we have a dealer in your local so we can make the after-sell service.If don't have,please contact us for the technical supports,we can full support you online
